FOTEK MA-21R-S MV/MA Series Preset Current Meter
- Brand
- FOTEK
- Model
- MA-21R-S
- GEARWELL SKU
- GWP-000021097
- Category
- Test & Measurement
Key specifications
- Input
- 0~5 A AC
- Outline
- 96x48 mm
- Transmitter
- 4~20 mA
- Power supply
- 90~265 VAC 50/60 Hz, 5 VA max.
- Display range
- 0~9999
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK MA-21R-S MV/MA Series Preset Current Meter |
|---|---|
| Brand | FOTEK |
| Model | MA-21R-S |
| Category | Test & Measurement |
| Input | 0~5 A AC |
| Outline | 96x48 mm |
| Transmitter | 4~20 mA |
| Power supply | 90~265 VAC 50/60 Hz, 5 VA max. |
| Display range | 0~9999 |
| Setting range | 0~9999 |
| Control output | Relay 1c, 5 A/250 VAC |
| Display accuracy | ±0.1% of F.S. +1 digit |
| Operating ambient | -20 ~ 75 °C, 35 ~ 85% RH |
