FOTEK LCR-80H LCR Series Three-Phase SCR Power Regulator

Key specifications

Load max.: 80 A
Cooling fan: 80x80 (220 VAC)
Input method: 4~20mA / 0~20mA / 1~5V / 2~10V / 0~5V / 0~10V / VR-10kΩ selectable
Rated current: 64 A
Surge current: 850 A

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	FOTEK LCR-80H LCR Series Three-Phase SCR Power Regulator
Brand	FOTEK
Model	LCR-80H
Category	Contactors & Starters
Load max.	80 A
Cooling fan	80x80 (220 VAC)
Input method	4~20mA / 0~20mA / 1~5V / 2~10V / 0~5V / 0~10V / VR-10kΩ selectable
Rated current	64 A
Surge current	850 A
Control method	Zero cross or phase angle control selectable
Protection fuse	100 A
Aux. power supply	90~265 VAC 50/60 Hz
Main power supply	280~550 VAC 50/60 Hz
Operating ambient	-20 ~ +80 °C, 35 ~ 85% RH
