FOTEK LSR-60AA+ LSR-AA Three Phase AC to AC Solid State Relay
- Brand
- FOTEK
- Model
- LSR-60AA+
- GEARWELL SKU
- GWP-000012968
- Category
- Contactors & Starters
Key specifications
- Type
- Standard AC to AC (cooling fan)
- Input voltage
- 20-265 VAC/DC
- Response time
- 8.3 ms (60 Hz)
- Control method
- Zero cross switching
- Trigger current
- 3 VA max.
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK LSR-60AA+ LSR-AA Three Phase AC to AC Solid State Relay |
|---|---|
| Brand | FOTEK |
| Model | LSR-60AA+ |
| Category | Contactors & Starters |
| Type | Standard AC to AC (cooling fan) |
| Input voltage | 20-265 VAC/DC |
| Response time | 8.3 ms (60 Hz) |
| Control method | Zero cross switching |
| Trigger current | 3 VA max. |
| Isolation strength | 4 kV rms (EN60950/VDE0805) |
| Load supply voltage | 90-550 VAC |
| Dimensions (W x D x H) | 100 x 112 (+26 fan) x 127 mm |
| Operating environment | -40 to +80 °C; 35-85% RH |
