FOTEK KTM-40-V KT Series Paddle Wheel Flow Meter with Transmitter
- Brand
- FOTEK
- Model
- KTM-40-V
- GEARWELL SKU
- GWP-000021095
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- KTM: flow rate meter & flow total meter with transmitter
- Accuracy
- ±1.0% of F.S. @ 25 °C
- Pipe size
- DN40 (1-1/2 in)
- Flow velocity
- 0.3 m/s min. ~ 10 m/s max.
- Protection class
- IP-65
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK KTM-40-V KT Series Paddle Wheel Flow Meter with Transmitter |
|---|---|
| Brand | FOTEK |
| Model | KTM-40-V |
| Category | Pressure, Flow & Temperature |
| Series | KTM: flow rate meter & flow total meter with transmitter |
| Accuracy | ±1.0% of F.S. @ 25 °C |
| Pipe size | DN40 (1-1/2 in) |
| Flow velocity | 0.3 m/s min. ~ 10 m/s max. |
| Protection class | IP-65 |
| Operating pressure | 5 kg/cm² |
| Transmitter option | V = 0~5 V |
| Pipe standard options | DIN / JIS / ANSI / flange / inserted / clamping (specify on order) |
| Material of union options | PP / PVDF / PVC / SUS 316 (specify on order) |
