DELTA VFD32AMS43AFSAA MS300 series AC Motor Drive
- Brand
- DELTA
- Model
- VFD32AMS43AFSAA
- GEARWELL SKU
- GWP-000011106
- Category
- Variable Frequency Drives
Key specifications
- Frame
- E2
- EMC filter
- Built-in EMC filter
- Brake chopper
- Built-in
- Dimensions W x H x D
- 130.0 x 250.0 x 219.0 mm
- Applicable motor output
- 15 / 20 kW / HP
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Delta VFD32AMS43AFSAA is an MS300 series compact AC motor drive for a 460 V 3-phase supply, rated 32 A output current in heavy duty for motors up to 15 kW (20 HP), built in frame size E. It accepts 380 to 480 V at 50/60 Hz (mains range 323 to 528 V) and delivers 36 A in normal duty. The model code marks an IP20 enclosure, built-in EMC filter and integrated Safe Torque Off (STO). Heavy-duty overload is 150% of rated current for 60 seconds and 200% for 3 seconds, and output frequency goes up to 599 Hz; it controls induction and permanent magnet motors in V/F, SVC or sensorless FOC mode. A built-in brake chopper, a 2k-step PLC and Modbus are included.
Technical reference
| Product name | DELTA VFD32AMS43AFSAA MS300 series AC Motor Drive |
|---|---|
| Brand | DELTA |
| Model | VFD32AMS43AFSAA |
| Category | Variable Frequency Drives |
| Frame | E2 |
| EMC filter | Built-in EMC filter |
| Brake chopper | Built-in |
| Dimensions W x H x D | 130.0 x 250.0 x 219.0 mm |
| Applicable motor output | 15 / 20 kW / HP |
| Rated voltage / frequency | 3-phase AC 380 V ~ 480 V (-15% ~ +10%), 50 / 60 Hz |
| Rated output current (Heavy Duty) | 32 A |
| Rated output current (Normal Duty) | 36 A |
