DELTA VFD300C43A-21 C2000 Plus AC Motor Drive
- Brand
- DELTA
- Model
- VFD300C43A-21
- GEARWELL SKU
- GWP-000029944
- Category
- Variable Frequency Drives
Key specifications
- Frame
- C
- Braking chopper
- Built-in for frames A, B, C
- Rated input voltage
- 3Ø, 380 ~ 480 VAC (-15% ~ +10%), 50/60 Hz
- Motor power (Heavy Duty)
- 30 kW / 40 HP
- Rated input current (HD / SHD)
- 63 / 47 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA VFD300C43A-21 C2000 Plus AC Motor Drive |
|---|---|
| Brand | DELTA |
| Model | VFD300C43A-21 |
| Category | Variable Frequency Drives |
| Frame | C |
| Braking chopper | Built-in for frames A, B, C |
| Rated input voltage | 3Ø, 380 ~ 480 VAC (-15% ~ +10%), 50/60 Hz |
| Motor power (Heavy Duty) | 30 kW / 40 HP |
| Rated input current (HD / SHD) | 63 / 47 A |
| Motor power (Super Heavy Duty) | 22 kW / 30 HP |
| Rated output current (Heavy Duty) | 60 A |
| Rated output current (Super Heavy Duty) | 45 A |
