Delta DOP-107BV HMI Touch Panel
- Brand
- DELTA
- Model
- DOP-107BV
- GEARWELL SKU
- GWP-000006932
- Category
- HMIs & Industrial PCs
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Delta DOP-107BV is a DOP 100 Series Basic Type HMI touch panel with a 7" TFT LCD at 800 x 480 pixels (WVGA) and 65,536 colors. It uses an ARM Cortex-A8 (800MHz) processor with 256 Mbytes flash ROM and 256 Mbytes RAM, and has no Ethernet port. Interfaces are USB slave and USB host, COM1 RS-232/RS-485 and COM2 RS-422/RS-485. It runs on DC +24V (max. 8.6 W), has an IP65 / NEMA4 front, and measures 215 x 161 x 35.5 mm with a weight of 700 g.
Technical reference
| Product name | Delta DOP-107BV HMI Touch Panel |
|---|---|
| Brand | DELTA |
| Model | DOP-107BV |
| Category | HMIs & Industrial PCs |
