DANFOSS 032U1239 EV220B 2/2-Way Solenoid Valve G 3/8 NO
- Brand
- DANFOSS
- Model
- 032U1239
- GEARWELL SKU
- GWP-000021623
- Category
- Valves & Manifolds
Key specifications
- Function
- NO (normally open), 2/2-way
- Kv value
- 0.7 m³/h
- Operation
- Servo-operated (diaphragm)
- Connection
- G 3/8 (ISO 228-1)
- Orifice size
- 6 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DANFOSS 032U1239 EV220B 2/2-Way Solenoid Valve G 3/8 NO |
|---|---|
| Brand | DANFOSS |
| Model | 032U1239 |
| Category | Valves & Manifolds |
| Function | NO (normally open), 2/2-way |
| Kv value | 0.7 m³/h |
| Operation | Servo-operated (diaphragm) |
| Connection | G 3/8 (ISO 228-1) |
| Orifice size | 6 mm |
| Type designation | EV220B 6 |
| Specification key | EV220B 6B G 38F NO000 |
| Body / seal material | Brass / FKM |
| Medium temperature | 0 to 100 °C |
| Differential pressure | 0.1 – 10 bar |
