DANFOSS 032U7115 EV220B 2/2-Way Solenoid Valve G 1/2 NC
- Brand
- DANFOSS
- Model
- 032U7115
- GEARWELL SKU
- GWP-000021625
- Category
- Valves & Manifolds
Key specifications
- Function
- NC (normally closed), 2/2-way
- Kv value
- 4 m³/h
- Operation
- Servo-operated (diaphragm)
- Connection
- G 1/2 (ISO 228-1)
- Orifice size
- 15 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DANFOSS 032U7115 EV220B 2/2-Way Solenoid Valve G 1/2 NC |
|---|---|
| Brand | DANFOSS |
| Model | 032U7115 |
| Category | Valves & Manifolds |
| Function | NC (normally closed), 2/2-way |
| Kv value | 4 m³/h |
| Operation | Servo-operated (diaphragm) |
| Connection | G 1/2 (ISO 228-1) |
| Orifice size | 15 mm |
| Type designation | EV220B 15 |
| Specification key | EV220B 15B G 12E NC000 |
| Body / seal material | Brass / EPDM |
| Medium temperature | -30 to 120 °C |
| Differential pressure | 0.3 – 16 bar |
