DANFOSS 032U3804 EV225B 2/2-Way Solenoid Valve G 1/2 NC
- Brand
- DANFOSS
- Model
- 032U3804
- GEARWELL SKU
- GWP-000021624
- Category
- Valves & Manifolds
Key specifications
- Function
- NC (normally closed), 2/2-way
- Kv value
- 2.2 m³/h
- Operation
- Servo-operated (diaphragm)
- Connection
- G 1/2 (ISO 228-1)
- Orifice size
- 10 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DANFOSS 032U3804 EV225B 2/2-Way Solenoid Valve G 1/2 NC |
|---|---|
| Brand | DANFOSS |
| Model | 032U3804 |
| Category | Valves & Manifolds |
| Function | NC (normally closed), 2/2-way |
| Kv value | 2.2 m³/h |
| Operation | Servo-operated (diaphragm) |
| Connection | G 1/2 (ISO 228-1) |
| Orifice size | 10 mm |
| Type designation | EV225B 10 |
| Specification key | EV225B 10BD G 12T NC000 |
| Body / seal material | DZR brass / PTFE |
| Medium temperature | -10 to 185 °C |
| Differential pressure | 0.3 – 10 bar |
