DANFOSS 032H8039 EV210A 2/2-Way Solenoid Valve G 1/4 NC
- Brand
- DANFOSS
- Model
- 032H8039
- GEARWELL SKU
- GWP-000021622
- Category
- Valves & Manifolds
Key specifications
- Function
- NC (normally closed), 2/2-way
- Kv value
- 0.17 m³/h
- Operation
- Direct-operated
- Connection
- G 1/4 (ISO 228-1)
- Orifice size
- 2.5 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DANFOSS 032H8039 EV210A 2/2-Way Solenoid Valve G 1/4 NC |
|---|---|
| Brand | DANFOSS |
| Model | 032H8039 |
| Category | Valves & Manifolds |
| Function | NC (normally closed), 2/2-way |
| Kv value | 0.17 m³/h |
| Operation | Direct-operated |
| Connection | G 1/4 (ISO 228-1) |
| Orifice size | 2.5 mm |
| Type designation | EV210A 2.5 |
| Specification key | EV210A 2.5SS G 14F NC000 |
| Body / seal material | Stainless steel / FKM |
| Medium temperature | -10 to 100 °C |
| Differential pressure | 0 – 20 bar |
