AZBIL HTY7043D4400 Neosensor Room Temperature/Humidity Sensor
- Brand
- AZBIL
- Model
- HTY7043D4400
- GEARWELL SKU
- GWP-000022467
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- Neosensor HTY7043D (two-wire 4-20 mA output)
- Company logo
- With company logo
- Power supply
- 24 V DC
- Humidity output
- 4-20 mA DC, 2-wire (linear to 0-100 %RH)
- Max. allowable load
- 500 Ω or lower
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AZBIL HTY7043D4400 Neosensor Room Temperature/Humidity Sensor |
|---|---|
| Brand | AZBIL |
| Model | HTY7043D4400 |
| Category | Pressure, Flow & Temperature |
| Series | Neosensor HTY7043D (two-wire 4-20 mA output) |
| Company logo | With company logo |
| Power supply | 24 V DC |
| Humidity output | 4-20 mA DC, 2-wire (linear to 0-100 %RH) |
| Max. allowable load | 500 Ω or lower |
| Temperature output | 4-20 mA DC, 2-wire (linear to 0-50 °C) |
| Temperature accuracy | ±0.3 °C (15-35 °C, 50 %RH) |
| Temperature measuring range | 0 to 50 °C |
