AZBIL HTY1010T1100 Durable Duct Temperature/Humidity Sensor
- Brand
- AZBIL
- Model
- HTY1010T1100
- GEARWELL SKU
- GWP-000022466
- Category
- Pressure, Flow & Temperature
Key specifications
- Type
- HTY1010: duct sensor
- Series
- Durable Temperature and Humidity Sensor (HTY1000 indoor / HTY1010 duct)
- Power supply
- 24 V DC, 24 V AC
- Output signal
- 1-5 V or 4-20 mA (selectable by output changeover switch; default 1-5 V)
- Dew point range
- -40 to 60 °C Td (at 10-100 %RH)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AZBIL HTY1010T1100 Durable Duct Temperature/Humidity Sensor |
|---|---|
| Brand | AZBIL |
| Model | HTY1010T1100 |
| Category | Pressure, Flow & Temperature |
| Type | HTY1010: duct sensor |
| Series | Durable Temperature and Humidity Sensor (HTY1000 indoor / HTY1010 duct) |
| Power supply | 24 V DC, 24 V AC |
| Output signal | 1-5 V or 4-20 mA (selectable by output changeover switch; default 1-5 V) |
| Dew point range | -40 to 60 °C Td (at 10-100 %RH) |
| Power consumption | Max. 7 VA (24 V AC) / max. 4 W (24 V DC) during drift recovery |
| Humidity measuring range | 0 to 100 %RH |
| Temperature measuring range | -20 to 60 °C |
