AZBIL HTY7043T1P00 Neosensor Room Temperature/Humidity Sensor
- Brand
- AZBIL
- Model
- HTY7043T1P00
- GEARWELL SKU
- GWP-000022469
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- Neosensor HTY7043
- Weight
- Approx. 80 g
- Company logo
- With company logo
- Power supply
- 24 V AC +10/-15 % (50/60 Hz), 24 V DC ±10 %
- Signal wiring
- Lead wire connection
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AZBIL HTY7043T1P00 Neosensor Room Temperature/Humidity Sensor |
|---|---|
| Brand | AZBIL |
| Model | HTY7043T1P00 |
| Category | Pressure, Flow & Temperature |
| Series | Neosensor HTY7043 |
| Weight | Approx. 80 g |
| Company logo | With company logo |
| Power supply | 24 V AC +10/-15 % (50/60 Hz), 24 V DC ±10 % |
| Signal wiring | Lead wire connection |
| Humidity output | 1-5 V DC (linear to 0-100 %RH) |
| Temperature output | RTD Pt100 (100 Ω at 0 °C, JIS C 1604 Class A) |
| Temperature accuracy | ±0.3 °C (at 0 to 60 °C) |
| Temperature measuring range | 0 to 60 °C |
