AZBIL HTY7803T4P00 HTY78_3 Duct Temperature/Humidity Sensor
- Brand
- AZBIL
- Model
- HTY7803T4P00
- GEARWELL SKU
- GWP-000022471
- Category
- Pressure, Flow & Temperature
Key specifications
- Type
- Long probe
- Series
- Duct Temperature/Humidity Sensor HTY78_3
- Enclosure
- IEC IP54
- Power supply
- 24 V DC / 24 V AC
- Humidity output
- 4-20 mA DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AZBIL HTY7803T4P00 HTY78_3 Duct Temperature/Humidity Sensor |
|---|---|
| Brand | AZBIL |
| Model | HTY7803T4P00 |
| Category | Pressure, Flow & Temperature |
| Type | Long probe |
| Series | Duct Temperature/Humidity Sensor HTY78_3 |
| Enclosure | IEC IP54 |
| Power supply | 24 V DC / 24 V AC |
| Humidity output | 4-20 mA DC |
| Humidity accuracy | ±3 %RH (30-70 %RH, at 25 °C) |
| Temperature output | RTD (Pt100) |
| Humidity measuring range | 0 to 100 %RH (non-condensing) |
| Temperature measuring range | -20 to 60 °C |
