Allen-Bradley 2198-DBR20-F Three-Phase EMC Line Filter
- Brand
- Allen-Bradley
- Model
- 2198-DBR20-F
- GEARWELL SKU
- GWP-000000571
- Category
- Drives and Motors
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 2198-DBR20-F is a AC line filter from Rockwell's Kinetix servo drive accessory range. It is an AC line filter for Kinetix 5500 multi-axis systems (2 axes of 2198-H003, H008 or H015-ERSx drives), the single 2198-H025-ERSx drive and the Kinetix 5700 2198-P031 DC-bus power supply. It is rated 528V AC max, three-phase 50/60 Hz, 20 A at 50 °C, with 4.2 W power loss and 1.0 kg weight, for 0…50 °C operation. With 2198-DBRxx-F line filters the maximum total motor-power cable length is up to 1200 m.
Technical reference
| Product name | Allen-Bradley 2198-DBR20-F Three-Phase EMC Line Filter |
|---|---|
| Brand | Allen-Bradley |
| Model | 2198-DBR20-F |
| Category | Drives and Motors |
