Allen-Bradley 2080-IQ4OB4 Micro800 4-Input 4-Output Digital I/O Plug-in Module

Brand: Allen-Bradley
Model: 2080-IQ4OB4
GEARWELL SKU: GWP-000002065
Category: PLCs & I/O

Key specifications

Digital output type: 4 current-sourcing transistor outputs, 12/24 V DC nominal class.
External power supply voltage: 10.8…30 V DC.
Maximum steady-state output current: 0.5 A per output.
Input impedance: 0…3 V: >4 kΩ; 3…12 V: 3.5 kΩ minimum; 12…30 V: >4 kΩ and <10 kΩ.
Input on-state voltage: 9…30 V DC or 10.25…30 V AC rms.

Micro800 2080 catalog number list (PDF, 114 KB)

Request a QuoteWhatsApp

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

← Back to products

Product overview

The Allen-Bradley 2080-IQ4OB4 is a Micro800 8-point combination plug-in module with 4 inputs for 12/24V DC (sink or source) and 4 source outputs for 12/24V DC, on a 12-pin terminal block. It fits any plug-in slot of a Micro820, Micro830, Micro850 or Micro870 controller; removal and insertion under power is not supported.

Technical reference

Product name	Allen-Bradley 2080-IQ4OB4 Micro800 4-Input 4-Output Digital I/O Plug-in Module
Brand	Allen-Bradley
Model	2080-IQ4OB4
Category	PLCs & I/O
Digital output type	4 current-sourcing transistor outputs, 12/24 V DC nominal class.
External power supply voltage	10.8…30 V DC.
Maximum steady-state output current	0.5 A per output.
Input impedance	0…3 V: >4 kΩ; 3…12 V: 3.5 kΩ minimum; 12…30 V: >4 kΩ and <10 kΩ.
Input on-state voltage	9…30 V DC or 10.25…30 V AC rms.
Input filter time, On-to-Off	8…10 ms for AC/DC inputs.
Isolation voltage	50 V continuous, basic insulation: inputs to outputs and I/O to backplane. I/O-to-backplane type test: 720 V DC for 60 s.
Output on-state voltage	10…30 V DC; 24 V DC nominal.
IEC input compatibility	Type 3
Digital inputs	4 sink/source inputs.
Digital outputs	4 sourcing transistor outputs.
Digital inputs configurable	No.
Digital outputs configurable	No.
