YASKAWA SGD7S-200A00A002 Sigma-7 SERVOPACK 200V 3.0kW Analog/Pulse
- Brand
- YASKAWA
- Model
- SGD7S-200A00A002
- GEARWELL SKU
- GWP-000024974
- Category
- Servo Systems
Key specifications
- Series
- Sigma-7 SGD7S single-axis
- Input current
- 15 Arms
- Voltage (code A)
- 200 VAC three-phase
- Code suffix "002"
- as collected; hardware-option code not listed in the official catalog model-number table
- Interface (code 00)
- Analog voltage/pulse train reference
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | YASKAWA SGD7S-200A00A002 Sigma-7 SERVOPACK 200V 3.0kW Analog/Pulse |
|---|---|
| Brand | YASKAWA |
| Model | SGD7S-200A00A002 |
| Category | Servo Systems |
| Series | Sigma-7 SGD7S single-axis |
| Input current | 15 Arms |
| Voltage (code A) | 200 VAC three-phase |
| Code suffix "002" | as collected; hardware-option code not listed in the official catalog model-number table |
| Interface (code 00) | Analog voltage/pulse train reference |
| Main circuit supply | 200-240 VAC -15%/+10%, 50/60 Hz |
| Continuous output current | 19.6 Arms |
| Instantaneous max. output current | 56 Arms |
| Maximum applicable motor capacity (code 200) | 3.0 kW |
