WAGO 739-206 739 Series PCB Terminal Block
- Brand
- WAGO
- Model
- 739-206
- GEARWELL SKU
- GWP-000012152
- Category
- Terminals, Cables & Connectors
Key specifications
- Color
- gray
- Width
- 44 mm
- Height
- 19 mm
- PCB contact
- THT
- Pin spacing
- 7.5 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The WAGO 739-206 is a 739 Series PCB terminal block with CAGE CLAMP® connection for 2.5 mm² conductors, actuated with an operating tool. It has 6 poles at 7.5 mm / 0.295 inches pin spacing and is gray. It is packed 100 per unit (subpackaging unit 25).
Technical reference
| Product name | WAGO 739-206 739 Series PCB Terminal Block |
|---|---|
| Brand | WAGO |
| Model | 739-206 |
| Category | Terminals, Cables & Connectors |
| Color | gray |
| Width | 44 mm |
| Height | 19 mm |
| PCB contact | THT |
| Pin spacing | 7.5 mm |
| Clamping units | 6 |
| Connection technology | CAGE CLAMP |
| Nominal cross-section | 2.5 mm² |
