TURCK BI40-CP80-FDZ30X2 CP80 Rectangular Inductive Sensor
- Brand
- TURCK
- Model
- BI40-CP80-FDZ30X2
- GEARWELL SKU
- GWP-000023171
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Housing
- Rectangular CP80, 80 x 80 x 41 mm, plastic PBT-GF30-V0
- Output function
- 2-wire, NC/NO programmable
- Protection class
- IP67
- Operating voltage
- 20...250 VAC / 10...300 VDC
- Mounting conditions
- Flush
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK BI40-CP80-FDZ30X2 CP80 Rectangular Inductive Sensor |
|---|---|
| Brand | TURCK |
| Model | BI40-CP80-FDZ30X2 |
| Category | Proximity & Photoelectric Sensors |
| Housing | Rectangular CP80, 80 x 80 x 41 mm, plastic PBT-GF30-V0 |
| Output function | 2-wire, NC/NO programmable |
| Protection class | IP67 |
| Operating voltage | 20...250 VAC / 10...300 VDC |
| Mounting conditions | Flush |
| Rated switching distance | 40 mm |
| Rated operational current | <= 400 mA AC / <= 300 mA DC |
| Connection version options | /S10 (terminal chamber, 1/2-14 NPT mounting base) / -B1131 / -B3131 (specify on order) |
