TURCK BI4-M12T-AP6X M12 Inductive Proximity Sensor PNP NO
- Brand
- TURCK
- Model
- BI4-M12T-AP6X
- GEARWELL SKU
- GWP-000023172
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Housing
- Threaded barrel M12 x 1, chrome-plated brass
- Ident no.
- 46080
- Output function
- 3-wire, NO contact, PNP
- Protection class
- IP67
- Operating voltage
- 10...30 VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK BI4-M12T-AP6X M12 Inductive Proximity Sensor PNP NO |
|---|---|
| Brand | TURCK |
| Model | BI4-M12T-AP6X |
| Category | Proximity & Photoelectric Sensors |
| Housing | Threaded barrel M12 x 1, chrome-plated brass |
| Ident no. | 46080 |
| Output function | 3-wire, NO contact, PNP |
| Protection class | IP67 |
| Operating voltage | 10...30 VDC |
| Ambient temperature | -25...+70 °C |
| Switching frequency | 2 kHz |
| Electrical connection | Cable 2 m, PVC, 3 x 0.34 mm² |
| Rated switching distance | 4 mm |
| DC rated operational current | <= 200 mA |
