TENGEN TGX01-100KW Full Cu with Breaker Autotransformer Starter
- Brand
- TENGEN
- Model
- TGX01-100KW Full Cu with Breaker
- GEARWELL SKU
- GWP-000021274
- Category
- Contactors & Starters
Key specifications
- Series
- TGX01 autotransformer reduced-voltage starter cabinet
- Rated voltage
- 380 V
- Material number
- 04080010663
- Rated motor power
- 100 kW
- Autotransformer taps
- 65% (60%) and 80%; supplied on 80%
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TENGEN TGX01-100KW Full Cu with Breaker Autotransformer Starter |
|---|---|
| Brand | TENGEN |
| Model | TGX01-100KW Full Cu with Breaker |
| Category | Contactors & Starters |
| Series | TGX01 autotransformer reduced-voltage starter cabinet |
| Rated voltage | 380 V |
| Material number | 04080010663 |
| Rated motor power | 100 kW |
| Autotransformer taps | 65% (60%) and 80%; supplied on 80% |
| Start time per start | <= 15 s (light-load, infrequent starting) |
| Output (start tap) voltage | 380 / 304 (80% tap) V |
| Current transformer ratio | 300/5 |
| Max operating current at 380 V | 187 A |
| Code suffix "全铜 带空开" (full copper, with circuit breaker) | as collected; this exact material number is not listed in the official SKU list; full-copper variant TGX01-100KW 全铜 is listed |
