TENGEN TGS51B-5/H 45A TGS51 Series Magnetic Motor Starter
- Brand
- TENGEN
- Model
- TGS51B-5/H 45A
- GEARWELL SKU
- GWP-000021271
- Category
- Contactors & Starters
Key specifications
- Version
- non-reversible (H, one contactor)
- Push buttons
- yes (LAY5-BE101/BE102)
- Starter size
- 5
- Material number
- 04070060076
- Coil control voltage
- 380 V AC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TENGEN TGS51B-5/H 45A TGS51 Series Magnetic Motor Starter |
|---|---|
| Brand | TENGEN |
| Model | TGS51B-5/H 45A |
| Category | Contactors & Starters |
| Version | non-reversible (H, one contactor) |
| Push buttons | yes (LAY5-BE101/BE102) |
| Starter size | 5 |
| Material number | 04070060076 |
| Coil control voltage | 380 V AC |
| Max. motor power at 380 V | 30 kW |
| Rated operational current | 60 A |
| Thermal relay setting range | 28-45 A |
| Contactor / thermal relay fitted | CJT1-60 / TGR36-63 |
