TENGEN TGX01-200KW Full Cu Autotransformer Starter Cabinet

Key specifications

Series: TGX01 autotransformer reduced-voltage starter cabinet
Rated voltage: 380 V
Material number: 04080010477
Rated motor power: 200 kW
Code suffix "全铜" (Full Cu): as collected; this exact material number is not listed in the official SKU list; series lists full-copper variants (copper wire and copper busbar), e.g. TGX01-100KW 全铜

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	TENGEN TGX01-200KW Full Cu Autotransformer Starter Cabinet
Brand	TENGEN
Model	TGX01-200KW Full Cu
Category	Contactors & Starters
Series	TGX01 autotransformer reduced-voltage starter cabinet
Rated voltage	380 V
Material number	04080010477
Rated motor power	200 kW
Code suffix "全铜" (Full Cu)	as collected; this exact material number is not listed in the official SKU list; series lists full-copper variants (copper wire and copper busbar), e.g. TGX01-100KW 全铜
Autotransformer taps	65% (60%) and 80%; supplied on 80%
Start time per start	<= 15 s (light-load, infrequent starting)
Output (start tap) voltage	380 / 304 (80% tap) V
Current transformer ratio	600/5
Max operating current at 380 V	367 A
