TENGEN TGX01-220KW Autotransformer Starter Cabinet
- Brand
- TENGEN
- Model
- TGX01-220KW
- GEARWELL SKU
- GWP-000021277
- Category
- Contactors & Starters
Key specifications
- Series
- TGX01 autotransformer reduced-voltage starter cabinet
- Rated voltage
- 380 V
- Material number
- 04080010024
- Rated motor power
- 220 kW
- Autotransformer taps
- 65% (60%) and 80%; supplied on 80%
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TENGEN TGX01-220KW Autotransformer Starter Cabinet |
|---|---|
| Brand | TENGEN |
| Model | TGX01-220KW |
| Category | Contactors & Starters |
| Series | TGX01 autotransformer reduced-voltage starter cabinet |
| Rated voltage | 380 V |
| Material number | 04080010024 |
| Rated motor power | 220 kW |
| Autotransformer taps | 65% (60%) and 80%; supplied on 80% |
| Start time per start | <= 15 s (light-load, infrequent starting) |
| Output (start tap) voltage | 380 / 304 (80% tap) V |
| Current transformer ratio | 600/5 |
| Max operating current at 380 V | 404 A |
