SICK 1061489 LFP0300-G2NMBS01 LFP Inox TDR Level Sensor
- Brand
- SICK
- Model
- 1061489
- GEARWELL SKU
- GWP-000015177
- Category
- Pressure, Flow & Temperature
Key specifications
- Note
- SICK description text quotes LFP0300-G1NMBS01; record name is LFP0300-G2NMBS01
- Housing
- Stainless steel with display, closed cover
- Outputs
- Current or voltage configurable; Q1 PNP; Q2 PNP/NPN
- Connection
- M12 x 1, 5-pin
- Probe length
- 300 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SICK 1061489 LFP0300-G2NMBS01 LFP Inox TDR Level Sensor |
|---|---|
| Brand | SICK |
| Model | 1061489 |
| Category | Pressure, Flow & Temperature |
| Note | SICK description text quotes LFP0300-G1NMBS01; record name is LFP0300-G2NMBS01 |
| Housing | Stainless steel with display, closed cover |
| Outputs | Current or voltage configurable; Q1 PNP; Q2 PNP/NPN |
| Connection | M12 x 1, 5-pin |
| Probe length | 300 mm |
| Article number | 1061489 |
| Process rating | 150 °C / 16 bar (CIP/SIP suitable) |
| Code suffix "S01" | probe bent 90°, bending radius 25 mm, active probe length 170 mm |
| Type designation | LFP0300-G2NMBS01 |
| Process connection | G 3/4 A, hygienic adaption |
