SICK 1062240 DBS36E-BBCP02048 Incremental Encoder

Key specifications

Article number: 1062240
Supply voltage: 7-30 V V
Connection type: Cable, 8-wire, with male connector, M12, 8-pin, universal, 0.5 m
Enclosure rating: IP65
Output frequency: ≤ 300 kHz

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	SICK 1062240 DBS36E-BBCP02048 Incremental Encoder
Brand	SICK
Model	1062240
Category	Encoders & Position
Article number	1062240
Supply voltage	7-30 V V
Connection type	Cable, 8-wire, with male connector, M12, 8-pin, universal, 0.5 m
Enclosure rating	IP65
Output frequency	≤ 300 kHz
Type designation	DBS36E-BBCP02048
Mechanical design	Blind hollow shaft, 8 mm Front clamp
Operating temperature	–20 °C ... +85 °C, –35 °C ... +95 °C on request
Pulses per revolution	2,048
Communication interface	TTL / RS-422
