Setra STC1SWP2MR430MG1 Model STC Wall-Mount RTD Temperature Sensor
- Brand
- Setra
- Model
- STC1SWP2MR430MG1
- GEARWELL SKU
- GWP-000022303
- Category
- Pressure, Flow & Temperature
Key specifications
- Housing
- ABS polycarbonate
- Output (P2)
- Pt100 RTD, 3-wire (resistance output)
- Range (MR4)
- 0 to 200 °C
- Configuration (W)
- Wall mount
- Probe length (30M)
- 300 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Setra STC1SWP2MR430MG1 Model STC Wall-Mount RTD Temperature Sensor |
|---|---|
| Brand | Setra |
| Model | STC1SWP2MR430MG1 |
| Category | Pressure, Flow & Temperature |
| Housing | ABS polycarbonate |
| Output (P2) | Pt100 RTD, 3-wire (resistance output) |
| Range (MR4) | 0 to 200 °C |
| Configuration (W) | Wall mount |
| Probe length (30M) | 300 mm |
| Mounting thread (G1) | G1/2" |
| Ordering-guide note | mounting thread position is tabulated for water-pipe mounting only; 'G1' as collected; wall mount is tabulated with probe length N; '30M' as collected; wall mount is footnoted with MR2 or resistance output; 'MR4' as collected; RTD outputs P1/P2 are tabulated with range 000 (resistance output); 'MR4' as collected (data sheet: for parameters not shown in the list contact the factory) |
| Ordering code breakdown | STC1-S-W-P2-MR4-30M-G1 |
| Sensing element accuracy | Industrial class A (IEC 751) |
| Ambient temperature (RTD output) | -40 to 85 °C |
