Setra STC1SW11MR210MG1 Model STC Wall-Mount Temperature Transmitter
- Brand
- Setra
- Model
- STC1SW11MR210MG1
- GEARWELL SKU
- GWP-000022300
- Category
- Pressure, Flow & Temperature
Key specifications
- Output (11)
- 4 to 20 mA (2-wire transmitter)
- Range (MR2)
- -10 to 70 °C
- Supply voltage
- 12 to 28 VDC
- Configuration (W)
- Wall mount
- Probe length (10M)
- 100 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Setra STC1SW11MR210MG1 Model STC Wall-Mount Temperature Transmitter |
|---|---|
| Brand | Setra |
| Model | STC1SW11MR210MG1 |
| Category | Pressure, Flow & Temperature |
| Output (11) | 4 to 20 mA (2-wire transmitter) |
| Range (MR2) | -10 to 70 °C |
| Supply voltage | 12 to 28 VDC |
| Configuration (W) | Wall mount |
| Probe length (10M) | 100 mm |
| Mounting thread (G1) | G1/2" |
| Ordering-guide note | mounting thread position is tabulated for water-pipe mounting only; 'G1' as collected; wall mount is tabulated with probe length N; '10M' as collected (data sheet: for parameters not shown in the list contact the factory) |
| Accuracy (transmitter) | ±0.3 °C @ 20 °C |
| Ordering code breakdown | STC1-S-W-11-MR2-10M-G1 |
| Ambient temperature (transmitter) | -10 to 70 °C |
