Setra 2091016BG2M1102 Model 209 Pressure Transducer

Key specifications

Output: 11 = 4 to 20 mA (2-wire)
Model code: 2091 = Model 209
Accuracy RSS: ±0.25 % FS
Pressure type: G = Gauge
Range code "016B": as collected; not listed in the official Model 209 model-number table (PSI range codes only)

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	Setra 2091016BG2M1102 Model 209 Pressure Transducer
Brand	Setra
Model	2091016BG2M1102
Category	Pressure, Flow & Temperature
Output	11 = 4 to 20 mA (2-wire)
Model code	2091 = Model 209
Accuracy RSS	±0.25 % FS
Pressure type	G = Gauge
Range code "016B"	as collected; not listed in the official Model 209 model-number table (PSI range codes only)
Wetted material	17-4 PH stainless steel
Pressure fitting	2M = 1/4" NPT male
Electrical termination	02 = 2 ft cable
Excitation (voltage output)	9 to 30 VDC
