Setra STC1SWP2000NN Model STC Wall-Mount RTD Temperature Sensor
- Brand
- Setra
- Model
- STC1SWP2000NN
- GEARWELL SKU
- GWP-000022302
- Category
- Pressure, Flow & Temperature
Key specifications
- Housing
- ABS polycarbonate
- Output (P2)
- Pt100 RTD, 3-wire (resistance output)
- Range (000)
- Resistance output (no transmitter range)
- Probe length (N)
- None (wall mount)
- Configuration (W)
- Wall mount
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Setra STC1SWP2000NN Model STC Wall-Mount RTD Temperature Sensor |
|---|---|
| Brand | Setra |
| Model | STC1SWP2000NN |
| Category | Pressure, Flow & Temperature |
| Housing | ABS polycarbonate |
| Output (P2) | Pt100 RTD, 3-wire (resistance output) |
| Range (000) | Resistance output (no transmitter range) |
| Probe length (N) | None (wall mount) |
| Configuration (W) | Wall mount |
| Measuring type (S) | Single point |
| Mounting thread (N) | None |
| Ordering code breakdown | STC1-S-W-P2-000-N-N |
| Sensing element accuracy | Industrial class A (IEC 751) |
| Ambient temperature (RTD output) | -40 to 85 °C |
