Setra STC1SIP100005MG1 Model STC Immersion RTD Temperature Sensor
- Brand
- Setra
- Model
- STC1SIP100005MG1
- GEARWELL SKU
- GWP-000022296
- Category
- Pressure, Flow & Temperature
Key specifications
- Housing
- Aluminium alloy; 304 stainless steel sensor sheath
- Output (P1)
- Pt1000 RTD, 3-wire (resistance output)
- Range (000)
- Resistance output (no transmitter range)
- Configuration (I)
- Water-pipe (immersion) mount
- Measuring type (S)
- Single point
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Setra STC1SIP100005MG1 Model STC Immersion RTD Temperature Sensor |
|---|---|
| Brand | Setra |
| Model | STC1SIP100005MG1 |
| Category | Pressure, Flow & Temperature |
| Housing | Aluminium alloy; 304 stainless steel sensor sheath |
| Output (P1) | Pt1000 RTD, 3-wire (resistance output) |
| Range (000) | Resistance output (no transmitter range) |
| Configuration (I) | Water-pipe (immersion) mount |
| Measuring type (S) | Single point |
| Probe length (05M) | 50 mm |
| Mounting thread (G1) | G1/2" |
| Ordering code breakdown | STC1-S-I-P1-000-05M-G1 |
| Sensing element accuracy | Industrial class A (EN 60751) |
| Ambient temperature (RTD output) | -40 to 85 °C |
