Setra SRH15PD2CT3N SRH Duct Mount Humidity Transmitter
- Brand
- Setra
- Model
- SRH15PD2CT3N
- GEARWELL SKU
- GWP-000022224
- Category
- Pressure, Flow & Temperature
Key specifications
- Note
- SSP-SRH Rev D (2013) footnote limited 5% units to passive temperature options; current Rev F table has no such restriction
- Display (N)
- None
- Output (2C)
- 0 to 5 or 0 to 10 VDC, user selectable (3-wire)
- Model code
- SRH1 (Model SRH)
- Accuracy (5P)
- ±5 % RH
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Setra SRH15PD2CT3N SRH Duct Mount Humidity Transmitter |
|---|---|
| Brand | Setra |
| Model | SRH15PD2CT3N |
| Category | Pressure, Flow & Temperature |
| Note | SSP-SRH Rev D (2013) footnote limited 5% units to passive temperature options; current Rev F table has no such restriction |
| Display (N) | None |
| Output (2C) | 0 to 5 or 0 to 10 VDC, user selectable (3-wire) |
| Model code | SRH1 (Model SRH) |
| Accuracy (5P) | ±5 % RH |
| Configuration (D) | Duct Mount |
| Sensing element | Capacitive polymer |
| Operating temperature | -40 to 60 °C |
| Temperature output (T3) | -58 to 140 °F (-50 to 60 °C) active |
| Humidity operating range | 0 to 99 (non-condensing) % RH |
