Setra SRH15PO11T2NC SRH Outside Air Humidity Transmitter
- Brand
- Setra
- Model
- SRH15PO11T2NC
- GEARWELL SKU
- GWP-000022836
- Category
- Pressure, Flow & Temperature
Key specifications
- Option (C)
- NIST Certificate of Performance
- Display (N)
- None
- Output (11)
- 4 to 20 mA
- Accuracy (5P)
- ±5 % RH
- Configuration (O)
- Outside Air
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Setra SRH15PO11T2NC SRH Outside Air Humidity Transmitter |
|---|---|
| Brand | Setra |
| Model | SRH15PO11T2NC |
| Category | Pressure, Flow & Temperature |
| Option (C) | NIST Certificate of Performance |
| Display (N) | None |
| Output (11) | 4 to 20 mA |
| Accuracy (5P) | ±5 % RH |
| Configuration (O) | Outside Air |
| Sensing element | Capacitive polymer |
| Moisture resistance | IP65, NEMA-4 (duct & outside air) |
| Suffix verification | Setra SRH ordering table: last position option C = NIST certificate of performance (the only option listed); every position of SRH1-5P-O-11-T2-N-C is in the table |
| Temperature output (T2) | 1000 Ω RTD (passive) |
| Humidity operating range | 0 to 99 (non-condensing) % RH |
