SemeaTech 052-1800-000 7H2S-20 7-Series H2S Electrochemical Sensor
- Brand
- SemeaTech
- Model
- 052-1800-000
- GEARWELL SKU
- GWP-000022752
- Category
- Test & Measurement
Key specifications
- Weight
- 8 g
- Part number
- 052-1800-000
- Humidity range
- 15 to 90 % RH, non-condensing
- Measuring range
- 0 to 20 ppm
- Housing material
- ABS
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SemeaTech 052-1800-000 7H2S-20 7-Series H2S Electrochemical Sensor |
|---|---|
| Brand | SemeaTech |
| Model | 052-1800-000 |
| Category | Test & Measurement |
| Weight | 8 g |
| Part number | 052-1800-000 |
| Humidity range | 15 to 90 % RH, non-condensing |
| Measuring range | 0 to 20 ppm |
| Housing material | ABS |
| Maximum overload | 50 ppm |
| Sensitivity (20 °C) | 2.5 ± 0.5 µA/ppm |
| Type designation | 7H2S-20 |
| Response time (T90) | ≤ 30 s |
| Operating temperature | -40 to 50 °C |
