SemeaTech 054-0300-000 H2-10000 7-Series Hydrogen Gas Sensor
- Brand
- SemeaTech
- Model
- 054-0300-000
- GEARWELL SKU
- GWP-000022753
- Category
- Test & Measurement
Key specifications
- Resolution
- 10 ppm
- Nominal range
- 0 to 10,000 ppm
- Humidity range
- 15 to 90 % RH, non-condensing
- Weight (nominal)
- 8 g
- Housing material
- ABS
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SemeaTech 054-0300-000 H2-10000 7-Series Hydrogen Gas Sensor |
|---|---|
| Brand | SemeaTech |
| Model | 054-0300-000 |
| Category | Test & Measurement |
| Resolution | 10 ppm |
| Nominal range | 0 to 10,000 ppm |
| Humidity range | 15 to 90 % RH, non-condensing |
| Weight (nominal) | 8 g |
| Housing material | ABS |
| Maximum overload | 20,000 ppm |
| Sensitivity (20 °C) | 0.006 ± 0.003 µA/ppm |
| Type designation | H2-10000 (7 Series) |
| Response time (T90) | ≤ 110 s |
| Temperature range | -20 to 50 °C |
