DEIF TAC-210DG/3 210DG AC Current Transducer

Key specifications

Accuracy: Class 0.5 (IEC 688)
Mounting: DIN rail
Protection: Case IP52, terminals IP20
Output options: 0..1/5/10/20 mA, 0..1/10 V, 4..20 mA and others (specify on order)
Measuring range: 0 ... 100% Inom

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	DEIF TAC-210DG/3 210DG AC Current Transducer
Brand	DEIF
Model	TAC-210DG/3
Category	Test & Measurement
Accuracy	Class 0.5 (IEC 688)
Mounting	DIN rail
Protection	Case IP52, terminals IP20
Output options	0..1/5/10/20 mA, 0..1/10 V, 4..20 mA and others (specify on order)
Measuring range	0 ... 100% Inom
Auxiliary supply	57.7 ... 440 V AC or 24 ... 220 V DC (specify on order)
Measured quantity	AC current (with auxiliary supply)
Measuring current	0.5 ... 10 A AC
