FOTEK SC-260 SC Series Multi-function Total Counter
- Brand
- FOTEK
- Model
- SC-260
- GEARWELL SKU
- GWP-000023378
- Category
- Test & Measurement
Key specifications
- Type
- Total Counter
- Output
- None (total counter)
- Display
- 6 digits
- Dimension
- 96 x 48 x 90 mm (cutout 92 x 45 mm)
- Power supply
- 110 / 220 V AC +/-20%, 50/60 Hz
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK SC-260 SC Series Multi-function Total Counter |
|---|---|
| Brand | FOTEK |
| Model | SC-260 |
| Category | Test & Measurement |
| Type | Total Counter |
| Output | None (total counter) |
| Display | 6 digits |
| Dimension | 96 x 48 x 90 mm (cutout 92 x 45 mm) |
| Power supply | 110 / 220 V AC +/-20%, 50/60 Hz |
| Divisor / multiplier | 1-9999 / 0.001-9.999 |
| Response frequency | High speed < 2.5 kcps, low speed < 60 cps |
| Sensor power output | 12 V DC / 60 mA max. |
| Operating temp./humidity | -20 to +80 C, 35-85% RH |
