Pfannenberg 17121000000 FLZ 530 Enclosure Thermostat
- Brand
- Pfannenberg
- Model
- 17121000000
- GEARWELL SKU
- GWP-000022843
- Category
- Pressure, Flow & Temperature
Key specifications
- Evidence
- Pfannenberg FLZ 510/520/530 thermostat datasheet (hosted at static.chipdip.ru)
- Setting range
- 0 ... +60 °C
- Article number
- 17121000000
- Type of contact
- N.O. with spring contact
- Type designation
- FLZ 530
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Pfannenberg 17121000000 FLZ 530 Enclosure Thermostat |
|---|---|
| Brand | Pfannenberg |
| Model | 17121000000 |
| Category | Pressure, Flow & Temperature |
| Evidence | Pfannenberg FLZ 510/520/530 thermostat datasheet (hosted at static.chipdip.ru) |
| Setting range | 0 ... +60 °C |
| Article number | 17121000000 |
| Type of contact | N.O. with spring contact |
| Type designation | FLZ 530 |
| Code as collected | FLZ 530(0~60°C) |
| Max. switching power | 120 V AC / 15 (2) A; DC max. 30 W |
| Mounting / connection | Snap fastening for 35 mm profile bars (EN 60715); screw terminals 0.5-2.5 mm² |
| Operating temperature | -40 ... +80 °C |
| Switching temperature difference | < 7 K |
