Pfannenberg 17111000000 FLZ 520 Enclosure Thermostat

Key specifications

Evidence: Pfannenberg FLZ 510/520/530 thermostat datasheet (hosted at static.chipdip.ru)
Setting range: 0 ... +60 °C
Article number: 17111000000
Type of contact: N.C. with spring contact
Type designation: FLZ 520

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	Pfannenberg 17111000000 FLZ 520 Enclosure Thermostat
Brand	Pfannenberg
Model	17111000000
Category	Pressure, Flow & Temperature
Evidence	Pfannenberg FLZ 510/520/530 thermostat datasheet (hosted at static.chipdip.ru)
Setting range	0 ... +60 °C
Article number	17111000000
Type of contact	N.C. with spring contact
Type designation	FLZ 520
Code as collected	17111000000
Max. switching power	240 V AC / 10 (2) A; DC max. 30 W
Mounting / connection	Snap fastening for 35 mm profile bars (EN 60715); screw terminals 0.5-2.5 mm²
Operating temperature	-40 ... +80 °C
Switching temperature difference	< 7 K
