People Electric XJ01-160kW Autotransformer Starter, Copper Winding
- Brand
- People Electric
- Model
- XJ01-160kW
- GEARWELL SKU
- GWP-000013755
- Category
- Contactors & Starters
Key specifications
- Code suffix "铜"
- as collected (copper-wound autotransformer); not listed in the official XJ01 model table
- Control mode
- manual and automatic
- Rating "160 kW"
- as collected; not in the official XJ01 rating table (14 ... 300 kW)
- Material number
- 101020002010065
- Autotransformer taps
- 65 % / 80 % of rated voltage
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | People Electric XJ01-160kW Autotransformer Starter, Copper Winding |
|---|---|
| Brand | People Electric |
| Model | XJ01-160kW |
| Category | Contactors & Starters |
| Code suffix "铜" | as collected (copper-wound autotransformer); not listed in the official XJ01 model table |
| Control mode | manual and automatic |
| Rating "160 kW" | as collected; not in the official XJ01 rating table (14 ... 300 kW) |
| Material number | 101020002010065 |
| Autotransformer taps | 65 % / 80 % of rated voltage |
| Controlled motor power | 160 kW |
| Starting time (adjustable) | 1~15 s |
| Rated operational voltage | AC 380 V |
