People Electric RDCPS(KBO)D-45C/M12/12M/06M CPS Two-Speed Controller
- Brand
- People Electric
- Model
- RDCPS(KBO)D-45C/M12/12M/06M
- GEARWELL SKU
- GWP-000020700
- Category
- Contactors & Starters
Key specifications
- Frame current
- 45 A
- Material number
- 101002012010081
- Auxiliary contacts
- 3 NO + 3 NC + 1 short-circuit signal + 1 fault signal (code 06)
- Code suffix "45" (frame)
- as collected; RDCPSD selection table lists frames 63 / 125 (45 frame is listed for RDCPS)
- Motor power at 380 V
- 3.2-4.8 kW
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | People Electric RDCPS(KBO)D-45C/M12/12M/06M CPS Two-Speed Controller |
|---|---|
| Brand | People Electric |
| Model | RDCPS(KBO)D-45C/M12/12M/06M |
| Category | Contactors & Starters |
| Frame current | 45 A |
| Material number | 101002012010081 |
| Auxiliary contacts | 3 NO + 3 NC + 1 short-circuit signal + 1 fault signal (code 06) |
| Code suffix "45" (frame) | as collected; RDCPSD selection table lists frames 63 / 125 (45 frame is listed for RDCPS) |
| Motor power at 380 V | 3.2-4.8 kW |
| Control supply voltage | AC 220 V |
| Breaking capacity class | C (Ics 12 kA at 380 V) |
| Long-delay setting current Ir | 4-12 A |
| High-speed controller rated current Ie | 12 A |
| Low-speed rated current (as collected "12M") | 12 A |
