PANASONIC HL-D301C HL-D3 Laser Displacement Sensor Head
- Brand
- PANASONIC
- Model
- HL-D301C
- GEARWELL SKU
- GWP-000021511
- Category
- Test & Measurement
Key specifications
- Beam size
- 50 um x 15 mm
- Lifecycle
- Discontinued
- Protection
- IP67 (excluding connector)
- Light source
- Red semiconductor laser 658 nm, Class 3R
- Sensing type
- Diffuse reflection
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | PANASONIC HL-D301C HL-D3 Laser Displacement Sensor Head |
|---|---|
| Brand | PANASONIC |
| Model | HL-D301C |
| Category | Test & Measurement |
| Beam size | 50 um x 15 mm |
| Lifecycle | Discontinued |
| Protection | IP67 (excluding connector) |
| Light source | Red semiconductor laser 658 nm, Class 3R |
| Sensing type | Diffuse reflection |
| Resolution (Z / X) | 1 / 5 um |
| Linearity (Z axis) | +/-0.1% F.S. |
| Measurement range (Z axis) | +/-10 mm |
| Measurement center distance | 50 mm |
| Measurement range (X axis, center) | 12.5 mm |
