PANASONIC HG-C1400 HG-C CMOS Micro Laser Distance Sensor
- Brand
- PANASONIC
- Model
- HG-C1400
- GEARWELL SKU
- GWP-000021510
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Linearity
- +/-0.2% F.S. (200-400 mm) / +/-0.3% F.S. (400-600 mm)
- Light source
- Red semiconductor laser, Class 2, 655 nm
- Analog output
- 0-5 V / 4-20 mA
- Beam diameter
- approx. 500 um
- Repeatability
- 300 (200-400 mm) / 800 (400-600 mm) um
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | PANASONIC HG-C1400 HG-C CMOS Micro Laser Distance Sensor |
|---|---|
| Brand | PANASONIC |
| Model | HG-C1400 |
| Category | Proximity & Photoelectric Sensors |
| Linearity | +/-0.2% F.S. (200-400 mm) / +/-0.3% F.S. (400-600 mm) |
| Light source | Red semiconductor laser, Class 2, 655 nm |
| Analog output | 0-5 V / 4-20 mA |
| Beam diameter | approx. 500 um |
| Repeatability | 300 (200-400 mm) / 800 (400-600 mm) um |
| Response time | 1.5 / 5 / 10 ms switchable |
| Control output | NPN open-collector, Light-ON/Dark-ON selectable |
| Supply voltage | 12-24 V DC +/-10% |
| Measuring range | +/-200 mm |
| Measurement center distance | 400 mm |
