PANASONIC HG-C1030 HG-C CMOS Micro Laser Distance Sensor
- Brand
- PANASONIC
- Model
- HG-C1030
- GEARWELL SKU
- GWP-000021508
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Linearity
- ±0.1 % F.S.
- Protection
- IP67 (IEC)
- Light source
- Red semiconductor laser Class 2, 655 nm
- Analog output
- 0-5 V / 4-20 mA
- Repeatability
- 10 µm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | PANASONIC HG-C1030 HG-C CMOS Micro Laser Distance Sensor |
|---|---|
| Brand | PANASONIC |
| Model | HG-C1030 |
| Category | Proximity & Photoelectric Sensors |
| Linearity | ±0.1 % F.S. |
| Protection | IP67 (IEC) |
| Light source | Red semiconductor laser Class 2, 655 nm |
| Analog output | 0-5 V / 4-20 mA |
| Repeatability | 10 µm |
| Response time | 1.5 / 5 / 10 switchable ms |
| Control output | NPN open-collector, max. 50 mA |
| Supply voltage | 12 to 24 ±10 % VDC |
| Measuring range | ±5 mm |
| Measurement center distance | 30 mm |
