OPTEX CD33-250CNV CD33 Laser Displacement Sensor, 0-10 V
- Brand
- OPTEX
- Model
- CD33-250CNV
- GEARWELL SKU
- GWP-000021631
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Linearity
- ±0.1% F.S.
- Connection
- Connector M12, 8-pin
- Light source
- Red semiconductor laser 655 nm, max. 1 mW, Class 2
- Analog output
- 0 to 10 V, output impedance 100 Ω
- Control output
- 2ch NPN open collector, max. 100 mA / 30 VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OPTEX CD33-250CNV CD33 Laser Displacement Sensor, 0-10 V |
|---|---|
| Brand | OPTEX |
| Model | CD33-250CNV |
| Category | Proximity & Photoelectric Sensors |
| Linearity | ±0.1% F.S. |
| Connection | Connector M12, 8-pin |
| Light source | Red semiconductor laser 655 nm, max. 1 mW, Class 2 |
| Analog output | 0 to 10 V, output impedance 100 Ω |
| Control output | 2ch NPN open collector, max. 100 mA / 30 VDC |
| Supply voltage | 18 to 24 VDC +10/-5% |
| Repeat accuracy | 75 µm |
| Measurement range | ±150 mm |
| Ambient temperature | -10 to +45 °C |
| Degree of protection | IP67 |
| Center of measurement range | 250 mm |
