OPTEX CD22-100-485M12 CD22 Laser Displacement Sensor, RS-485
- Brand
- OPTEX
- Model
- CD22-100-485M12
- GEARWELL SKU
- GWP-000021650
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Linearity
- ±0.1% F.S.
- Connection
- Pigtail cable with M12 5-pin connector, 300 mm
- Light source
- Red semiconductor laser 655 nm, 1 mW, Class 2
- Supply voltage
- 12 to 24 VDC ±10%
- Code suffix "M12"
- as collected; the official model table lists the 100 mm RS-485 type as CD22-100-485M122
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OPTEX CD22-100-485M12 CD22 Laser Displacement Sensor, RS-485 |
|---|---|
| Brand | OPTEX |
| Model | CD22-100-485M12 |
| Category | Proximity & Photoelectric Sensors |
| Linearity | ±0.1% F.S. |
| Connection | Pigtail cable with M12 5-pin connector, 300 mm |
| Light source | Red semiconductor laser 655 nm, 1 mW, Class 2 |
| Supply voltage | 12 to 24 VDC ±10% |
| Code suffix "M12" | as collected; the official model table lists the 100 mm RS-485 type as CD22-100-485M122 |
| Repeat accuracy | 20 µm |
| Serial interface | RS-485 half duplex (9.6 k to 1,250 kbps) |
| Measurement range | ±50 mm |
| Degree of protection | IP67 |
| Center of measurement range | 100 mm |
