OMRON NA5-15W101B-V1 NA Series HMI Programmable Terminal

Product overview

The OMRON NA5-15W101B-V1 is an NA5 programmable terminal (Sysmac machine interface) with a 15.4 inch wide screen, 1280 × 800 dots, black frame and metal case. It has a TFT LCD with 16,770,000 colors (24 bit full colors), an analog resistive membrane touch panel, 3 function keys and 256 MB of user data capacity, 2 Ethernet ports (up to 1000Base-T), 2 USB host ports, 1 USB slave port, an RS-232C serial port and an SD Memory Card slot. It runs on 24 VDC (19.2 to 28.8 VDC) and works from 0 to 50°C. Power consumption is 29 W max.; it measures 420 × 291 × 69 mm (W × H × D) and weighs 3.2 kg max.
