OMRON DRT2-MD16TA-1 DRT2 DeviceNet Slaves DeviceNet remote I/O terminal, 8 in / 8 out PNP, 3-tier terminal block
- Brand
- OMRON
- Model
- DRT2-MD16TA-1
- GEARWELL SKU
- GWP-000031325
- Category
- PLCs & I/O
Key specifications
- I/O points
- 8 inputs / 8 outputs
- Input current
- 6.0 mA max./point at 24 V DC
- Input ON voltage
- 15 V DC min.
- Internal I/O common
- PNP
- Rated output current
- 0.5 A/point
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OMRON DRT2-MD16TA-1 DRT2 DeviceNet Slaves DeviceNet remote I/O terminal, 8 in / 8 out PNP, 3-tier terminal block |
|---|---|
| Brand | OMRON |
| Model | DRT2-MD16TA-1 |
| Category | PLCs & I/O |
| I/O points | 8 inputs / 8 outputs |
| Input current | 6.0 mA max./point at 24 V DC |
| Input ON voltage | 15 V DC min. |
| Internal I/O common | PNP |
| Rated output current | 0.5 A/point |
| Input/Output ON delay | 1.5 ms / 0.5 ms max. |
| Output residual voltage | 1.2 V max. at 0.5 A |
