OMRON CP1L-M30DT1-D CP1L Compact PLC
- Brand
- OMRON
- Model
- CP1L-M30DT1-D
- GEARWELL SKU
- GWP-000007814
- Category
- PLCs & I/O
Key specifications
- Weight
- 495 g
- Digital inputs
- 18
- Supply voltage
- 24 V DC
- Digital outputs
- 12 (PNP)
- Program capacity
- 10 K steps
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The OMRON CP1L-M30DT1-D is a CP1L-M compact PLC CPU unit with 30 I/O points: 18 inputs and 12 sourcing (PNP) transistor outputs. It is powered from 24 VDC (20.4 to 26.4 VDC) with 20 W max. power consumption. Program capacity is 10K steps; the high-speed counters handle 100 kHz on 4 axes and the pulse outputs 100 kHz on 2 axes for positioning. It has a built-in USB peripheral port, and Option Boards add RS-232C or RS-422A/485 serial communications.
Technical reference
| Product name | OMRON CP1L-M30DT1-D CP1L Compact PLC |
|---|---|
| Brand | OMRON |
| Model | CP1L-M30DT1-D |
| Category | PLCs & I/O |
| Weight | 495 g |
| Digital inputs | 18 |
| Supply voltage | 24 V DC |
| Digital outputs | 12 (PNP) |
| Program capacity | 10 K steps |
| Dimensions (H x W x D) | 90 x 130 x 85 mm |
| Operating temperature | 0 to 55 °C |
| Max. pulse output frequency | 100 kHz |
